EOS 2000D

Image Sensor

• Type

  Approx. 22.3 mm x 14.9 mm CMOS

• Effective Pixels

  Approx. 24.1 megapixels

• Total Pixels

  Approx. 24.7 megapixels

• Aspect Ratio

  3:2

• Low-Pass Filter

  Built-in/Fixed

• Sensor Cleaning

  Manual cleaning and Dust Delete Data acquisition

• Colour Filter Type

  RGB Primary Colour

Image Processor

• Type

  DIGIC 4+

Lens

• Lens Mount

  EF/EF-S

• Focal length

  Equivalent to 1.6x the focal length of the lens

• Image Stabilisation

  Optical Image Stabilizer provided on compatible lenses

Focusing

• Type

  Via optical viewfinder:
  TTL secondary image-forming phase-difference detection system with AF-dedicated sensor
  Via Live View on LCD screen:
  Contrast detection AF

• AF System / Points

  Via optical viewfinder:
  9 AF points (f/5.6 cross type at centre)

• AF working range

  Via optical viewfinder:
  Centre AF point: EV 0 -18 (at room temperature & ISO100)
  Other AF points: EV 1 -18 (at room temperature & ISO100)
  Via Live View LCD screen:
  EV 1 -18 (at room temperature & ISO100)

• AF Modes

  Via optical viewfinder:
  AI Focus (Switches between One-Shot AF and AI SERVO AF automatically)
  One Shot AF
  AI Servo
  Manual
  Via Live View LCD screen:
  One Shot AF (Contrast detect AF)
  Quick Mode (via phase detection AF sensor)
  Manual

• AF Point Selection

  Via optical viewfinder:
  Automatic selection from up to 9 points
  Manual selection
  Via Live View on LCD screen:
  FlexiZone – Freely position 1 AF point via manual selection
  Live Mode – Automatic selection with face detection

• Selected AF point display

  Indicated by superimposed display in the viewfinder and on the LCD monitor

• Predictive AF

  Yes

• AF Lock

  Locked when shutter button is pressed half way in One Shot AF mode. Customisation available via AE Lock Button

• AF Assist Beam

  Intermittent firing of built-in flash or emitted by optional dedicated Speedlite (effective up to 4.0 m)

• Manual Focus

  Selected on lens

Exposure Control

• Metering modes

  Via optical viewfinder:
  Evaluative via 63 zone dual-layer metering sensor (linked to all AF points)
  Partial (centre, approx. 10% of viewfinder)
  Centre-weighted average available
  Via Live View on LCD screen:
  Evaluative metering (315 zones)

• Metering Range

  Via optical viewfinder:
  EV 1-20 (at room temperature, ISO 100, evaluative metering)
  Via Live View on LCD screen:
  EV 0-20 (at room temperature, ISO 100, evaluative metering)

• AE Lock

  Auto: In 1-shot AF mode with evaluative metering exposure is locked when focus is achieved.
  Manual: By AE lock button in creative zone modes.

• Exposure Compensation

  +/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB).

• AEB

  3 shots +/- 2 EV, 1/2 or 1/3-stop increments

• ISO Sensitivity

  AUTO(100-6400), 100-6400 in 1-stop increments
  ISO can be expanded to H: 12800¹
  During Movie shooting: Auto (100-6400), 100-6400 (Whole stop increments)

Shutter

• Type

  Electronically-controlled focal-plane shutter, with electronic first curtain

• Speed

  30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)

White Balance

• Type

  Auto white balance with the imaging sensor

• Settings

  AWB (Ambience priority, White priority), Daylight, Shade, Cloudy, Tungsten, White Fluorescent light, Flash, Custom (Approx. 2000 K – 10000 K).
  White balance compensation:
  Blue/Amber +/-9
  Magenta/ Green +/-9.

• Custom White Balance

  Yes, 1 setting can be registered

• WB Bracketing

  +/-3 levels in single level increments
  3 bracketed images per shutter release.
  Selectable Blue/Amber bias or Magenta/Green bias.

Viewfinder

• Type

  Pentamirror

• Coverage (Vertical/Horizontal)

  Approx. 95%

• Magnification

  Approx. 0.80x²

• Eyepoint

  Approx. 21mm (from eyepiece lens center)

• Dioptre Correction

  -2.5 to +0.5 m-1 (dioptre)

• Focusing Screen

  Fixed

• Mirror

  Quick-return half mirror

• Depth of field preview

  Yes, assigned to SET button

• Eyepiece shutter

  On strap

LCD Monitor

• Type

  7.5 cm (3.0″) TFT LCD, approx. 920 K dots

• Coverage

  Approx. 100%

• Viewing Angle (horizontally/vertically)

  Approx. 170°

• Brightness Adjustment

  Adjustable to one of seven levels

• Display Options

  Quick Control Screen
  Camera settings

Flash

• Built-in Flash GN (ISO 100, meters)

  9.2

• Built-in Flash Coverage

  up to 17mm focal length (35mm equivalent: 28mm)

• Built-in Flash recycle time

  Approx. 2 seconds

• Modes

  Auto, Manual Flash On/off

• Red-Eye Reduction

  Yes – with red eye reduction lamp

• X-sync

  Cameras manufactured before September 2020 are not equipped with an X-contact³, Max. flash sync speed: 1/200 sec. with compatible Speedlites

• Flash Exposure Compensation

  +/- 2EV in 1/2 or 1/3 increments

• Flash Exposure Lock

  Yes

• Second Curtain Synchronisation

  Yes

• HotShoe / PC terminal

  Yes/No

• External Flash Compatibility

  E-TTL II with EX series Speedlites³

• External Flash Control

  Available via camera menu screen, except for wireless radio flash shooting settings

Shooting

• Modes

  Scene Intelligent Auto, No Flash, Creative Auto, Portrait, Landscape, Close-up, Sports, Food, Night Portrait, Movie, Program AE , Shutter priority AE, Aperture priority AE, Manual

• Picture Styles

  Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Defined (x3)

• Colour Space

  sRGB and Adobe RGB

• Image Processing

  Highlight Tone Priority
  Auto Lighting Optimizer (4 settings)
  Long exposure noise reduction
  High ISO speed noise reduction (4 settings)
  Auto Correction of Lens Peripheral illumination (up to 36 lens profiles can be registered in camera)
  Creative filters (Grainy B/W, Soft focus, Toy camera, Miniature effect, Fish-eye) – during image Playback only

• Drive modes

  Single, Continuous, Self timer (2s, 10s, 10s + continuous shots 2-10)

• Continuous Shooting

  Max. Approx. 3 fps for approx. 150 JPEG images⁴, 11 images RAW⁵⁶

Live View Mode

• Coverage

  Approx. 100% (horizontally and vertically)

• Frame Rate

  29.97 fps

• Focusing

  Live Mode: One Shot AF (Contrast detect AF)
  Quick Mode: One Shot AF (phase detection AF sensor)
  Manual (Magnification 5x or 10x available)

• Metering

  Real-time evaluative metering with image sensor
  Active metering time can be changed

• Display Options

  Grid overlay (x2), Histogram

File Type

• Still Image Type

  JPEG: Fine, Normal (Exif 2.30 compliant) / Design rule for Camera File system (2.0),
  RAW: RAW (14bit, Canon original RAW 2nd edition),
  Digital Print Order Format [DPOF] Version 1.1 compliant

• RAW+JPEG simultaneous recording

  Yes, RAW + Large JPEG

• Image Size

  JPEG 3:2: (L) 6000 x 4000, (M) 3984 x 2656, (S1) 2976 x 1984, (S2) 1920 x 1280, (S3) 720 x 480
  JPEG 4:3: (L) 5328 x 4000, (M) 3552 x 2664, (S1) 2656 x 1992, (S2) 1696 x 1280, (S3) 640 x 480
  JPEG 16:9: (L) 6000 x 3368, (M) 3984 x 2240, (S1) 2976 x 1680 (S2) 1920 x 1080, (S3) 720 x 408
  JPEG 1:1: (L) 4000 x 4000, (M) 2656 x 2656, (S1) 1984 x 1984, (S2) 1280 x 1280, (S3) 480 x 480
  RAW: (RAW) 6000 x 4000

• Movie Type

  MOV (Video: H.264 inter frame (IPB), Sound: Linear PCM, recording level can be manually adjusted by user)

• Movie Size

  1920 x 1080 (30, 25, 24 fps)
  1280 x 720 (60, 50 fps)
  640 x 480 (30, 25 fps)

• Movie Length

  Max duration 29 min 59 sec, Max file size 4 GB

• Folders

  New folders can be manually created and selected

• File Numbering

  Consecutive numbering
  Auto reset
  Manual reset

Other Features

• Custom Functions

  11 Custom Functions

• Metadata Tag

  User copyright information (can be set in camera)
  Image rating (0-5 stars)

• Intelligent Orientation Sensor

  Yes

• Playback zoom

  1.5x – 10x enabled in 15 steps

• Display Formats

  (1) Single image with information (2 levels)
  (2) Single image
  (3) Index display (4/9 images)
  (4) Jump Display (1/10/100 images, by Date, by Folder, Movies only, Stills only, by Rating)

• Slide Show

  Image selection: All images, by Date, by Folder, Movies, Stills, Rating
  Playback time: 1/2/3/5/10 or 20 seconds
  Repeat: On/Off
  Transition Effect: Off, Slide 1, Slide 2, Fade 1, Fade 2, Fade 3
  Background Music: On, Off

• Histogram

  Brightness: Yes
  RGB: Yes

• Highlight Alert

  Yes

• Image Erase/Protection

  Erase: Single image, selected images, all images in folder or all images on card
  Protection: Erase protection for single image, all images in a folder or all images in the card

• Menu Categories

  (1) Shooting menu (x4)
  (2) Playback menu (x2)
  (3) Setup menu (x3)
  (4) My Menu

• Menu Languages

  25 Languages
  English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean and Japanese

• GPS

  Compatible with GPS receiver GP-E2

• Firmware Update

  Update possible by the user.

Interface

• Computer

  Hi-Speed USB only

• Wi-Fi

  Wi-Fi (IEEE802.11b/g/n), (2.4 GHz only)⁷
  Connectivity to Smart devices is possible via Canon Camera Connect app⁸

• Wi-Fi Security

  Camera Access Point: WPA2-PSK with AES encryption or open
  Infrastructure: Shared key, with WEP encryption, WPA-PSK/WPA2-PSK with TKIP/AES encryption or open

• NFC

  NFC connectivity is possible only with compatible Canon or Android devices.

• Other

  HDMI mini (Type-C) output

Direct Print

• Canon Printers

  Canon Compact Photo Printers and PIXMA Printers supporting PictBridge

• PictBridge

  Yes

Storage

• Type

  SD card, SDHC card or SDXC card

Supported Operating System

• PC & Macintosh

  Windows 10 / 8.1 / 7 SP1⁹
  Mac OS X 10.10 – 10.13

Software

• Image Processing

  Digital Photo Professional (RAW Image Processing)

• Other

  EOS Utility
  EOS Lens Registration Tool
  EOS Web Service Registration Tool
  EOS Sample Music
  Picture Style Editor
  Camera Connect app available on iOS and Android devices¹⁰

Power Source

• Batteries

  1 x Rechargeable Li-ion Battery LP-E10

• Battery life

  Approx. 500 (at 23°C, AE 50%, FE 50%)¹¹
  Approx. 410 (at 0°C, AE 50%, FE 50%)

• Battery Indicator

  4 levels

• Power saving

  Power turns off after 30 sec or 1, 2, 4, 8 or 15 mins.

• Power Supply & Battery Chargers

  Battery charger LC-E10E
  Compact power adapter CA-PS700, DC coupler DR-E10

Weight and Dimensions

• Body Materials

  Polycarbonate resin with glass fibre & special conductive fibre

• Operating Environment

  0 – 40 °C, 85% or less humidity

• Dimensions (H x W x D)

  129.0 x 101.3 x 77.6mm

• Weight (body only)

  Approx. 475 g (CIPA testing standard, including battery and memory card)

Accessories

• Viewfinder

  Eyecup EF
  Rubber Frame EF
  E-series Dioptric Adjustment Lenses
  Eyepiece Extender EP-EX15II
  Angle Finder C
  Magnifier MG-EF

• Case

  Semi Hard Case EH26-L, EH27-L
  Protecting Cloth PC-E1, PC-E2
  Shoulder Bag SB10, SB100
  Backpack BP10, BP12, BP100
  Messenger Bag MS10, MS11
  Sling Bag SL100
  Holster HL100

• Lenses

  All EF and EF-S lenses

• Flash

  Canon Speedlites (270EX II, 430EX III-RT, 600EX II-RT, Macro-Ring-Lite MR-14EX II, Macro Twin Lite MT-26EX-RT, Speedlite Transmitter ST-E2, Speedlite Transmitter ST-E3-RT)¹²

• Remote Controller / Switch

  Remote Switch RS-60E3,
  Timer Remote Controller TC-80N3 via Remote Controller Adapter RA-E3

• Other

  Hand Strap E2, GPS Receiver GP-E2, HDMI Cable HTC-100, Interface Cable IFC400PCU

Physical Specifications

• Dimensions (WxHxD)

  129.0 x 101.3 x 77.6mm

• Batteries

  1 x Rechargeable Li-ion Battery LP-E10

• Battery life

  Approx. 500 (at 23°C, AE 50%, FE 50%)
